Valeso 313 siphon for sinks with side overflow

Description Valeso 313 siphon for sinks with lateral overflow

Siphon for sinks with a European standard drain (sink drain opening approx. 90 mm). The diameter of the siphon drain neck is 114 mm.

• Bottle-type trap.
• White heat-resistant plastic.
• Complete set including seals, stainless steel overflow screw, etc.
• Central drain screw made of stainless steel.
• Manual valve with debris collector.

The height of the trap relative to the drain neck can be adjusted. Thanks to the corrugated overflow and drain pipes, their length can be adjusted within the specified range. The outlet diameter to the sewage system can be selected as 50 mm or 40 mm. To connect the siphon to a 40 mm sewage pipe, one step of the outlet nozzle (the one with a 50 mm diameter) must be removed.
